Lenovo Series One Gen 2 Large Room Kit – Google Meet Hardware

Image:

• 20.30 Megapixels 1? CMOS Sensor
• 1080p Full HD @ 30 fps
• 720p HD @ 30 fps
• 17MP @ .5 fps
• 16:9 aspect ratio output

Optics:

• Horizontal field of view 90-95 ?
• Vertical field of view 90 ?
• Diagonal FOV: 103 degrees
• 4.3x lossless zoom

Connections:

• RJ45 Ethernet with PoE

Microphone:

• Omnidirectional

Dimensions & Weight:

• Length: 84 mm
• Width: 121 mm
• Height: 52 mm
• Weight: 480 g

Speaker:

• 3″ neodymium woofer
• .75″ neodymium tweeter
• 2 x passive radiators
• 20W RMS Power
• 80Hz – 24kHz Frequency response

Microphone:

• 8 element, linear beamforming array

Connections:

• AC/DC 48Vdc input
• USB-C with USB 2.0 UAC
• Stereo Analog RCA output for assistive listening devices
• RJ45 Ethernet with PoE
• 2 x RJ45 PoE-like, daisy chain output ports with data and power

Dimensions & Weight:

• Length: 95 mm
• Width: 705 mm
• Height: 133 mm
• Weight: 3.3 kg

Speaker:

• 3″ neodymium woofer
• .75″ neodymium tweeter
• 2 x passive radiators
• 20W RMS Power
• 80Hz – 24kHz Frequency response

Microphone:

• 8 element, linear beamforming array

Dimensions & Weight:

• Length: 95 mm
• Width: 705 mm
• Height: 133 mm
• Weight: 2.8 kg

Microphone:

• 8 element, circular beamforming array

Ports:

• RJ45 Daisy Chain input port for data and power
• RJ45 Daisy Chain output port for data and power

Dimensions & Weight:

• Length: 95 mm
• Width: 95 mm
• Height: 30 mm
• Weight: 215 g

CPU:

• Intel i7-8550U

Memory:

• 4GB Ram

Storage:

• 128GB SSD

Wireless Data Network:

• Dual-band WiFi (802.11AC) support: 2.4 GHz / 5 GHz
• Dual-mode Bluetooth 4.2 support

Ports:

• 2 HDMI 1.4 output video ports, with CEC support
• 1 HDMI 1.4 input video port
• Five RJ-45 Ethernet ports
• One gigabit Ethernet uplink port for Internet connection
• Four gigabit Ethernet downlink ports for IP-based peripherals
• Four USB ports: 3 Type-A and 1 Type-C ports
• Headphone jack with microphone support (3.5 mm)

Dimensions & Weight:

• Length: 135 mm
• Width: 284 mm
• Height: 29 mm
• Weight: 985 g

Screen:

• 10.1? Anti-smudge touchscreen

Display:

• 1280 x 800

Connections:

• 1x RJ45 10Gb PoE Connector

Dimensions & Weight:

• Length: 150 mm
• Width: 252 mm
• Height: 92 mm
• Weight: 990 g (with Metal Cover Plate)
